Physics Based and Data Driven Anomaly Detection Methods Using Vibration Data for Early Gear Damage Detection in Planetary Gearboxes
##plugins.themes.bootstrap3.article.main##
##plugins.themes.bootstrap3.article.sidebar##
https://orcid.org/0000-0002-1730-0582
Martin Dazer
Abstract
Various methods are known for using vibration sensors to distinguish anomalies such as pitting damage from normal operating conditions in gear drives. These methods are capable of detecting severe damage. However, to take full advantage of prognostics and health management (PHM) strategies, it is necessary to detect damage in a very early damage state. The objective of this work is therefore to analyze, improve and expand the known data evaluation methods in order to achieve the earliest possible detection of gear pitting damage during operation. The research question is: What is the smallest detectable pitting size in planetary gears using vibration data, and which methods are best suited for detection? A high-resolution vibration data set from a single-stage helical planetary gearbox is available for this study. The vibrations were recorded at different speeds, torque levels, and sensor positions. The evaluation methods include entirely physicsbased methods in the frequency and time domain, especially a selective analysis of characteristic frequencies and sidebands. These methods are supplemented with data driven approaches such as similarity analysis of frequency spectra. In contrast to physics-based methods, data- riven approaches aim to detect deviations of data sets regardless of their origin. To exclude false positives, these approaches inevitably require the use of multiple measurements without damage as a reference. The application of these methods results in the calculation of 130 condition indicators (CIs). This study provides statistical evidence for the detectability of small damage sizes, particularly using data-driven methods. The key findings of the study are that most of the information about the damage is contained in a comparison of full spectra. A comparison of the full spectral range provides a much clearer picture of damage compared to the analysis of individual characteristic frequencies.
How to Cite
##plugins.themes.bootstrap3.article.details##
Planetary Gearbox, Damage Detection, Vibration, Condition Monitoring, Pitting
